ProbitSite | The DALI Multimeter

Get it right the first time with ProbitSite!

Ensure every DALI installation runs smoothly with ProbitSite, the ultimate DALI multimeter. Designed for ease of use, this powerful tool allows you to quickly identify, document, and fix issues in any DALI installation. A simple, on-site DALI check that’s as straightforward as using a multimeter. Developed by experts with over 25 years of DALI experience, ProbitSite makes DALI debugging a breeze. Just connect it to the DALI lines, and it automatically detects any problems. It's even compatible for KNX DALI testing.

ProbitSite is now available for order!

Features

• DALI installation check – We provide transparency for any DALI installation to ensure its quality.
• Use SmartScan to recognize and read each device without touching the configuration.
• Prove and document the proper functioning of the DALI installation. Avoid the need to come back later.
• ProbitSite measures the quality of the DALI signal. Ideal for DALI debugging.
• Identify devices that are not DALI certified. A good starting point if things are not running smoothly. ProbitSite automatically compares the installed DALI devices with the DiiA database of certified products.
• Thanks to the integrated DALI power supply, ProbitSite can work on really any installation.
• The ProbitSite is compatible with the ProbitBench software to enable additional functions. Use its mediator feature to transmit IEC62386 commands and to display the corresponding answer.
• This DALI tool is suitable for the construction site: battery-operated, robust housing, low weight.

Technical Specifications Probitsite

• Charging 5VDC 500mA via USB-C
• Built-in memory for >30,000 bus readings
• Connection to DALI bus via 4mm banana sockets
• TFT display 320 x 480 px with 600cd/m²
• LiPo battery with approx. 8h runtime
• Size approx. 80mm x 165mm x 27mm
• Weight approx. 300g
• IP protection IP20
• Ambient temperature for operation and storage: +10 to +35 °C
• GTIN 4262466940009
• The product falls under Directive 2012/19/EU (Battery Disposal) and must not
be disposed of with household waste.

DALI Technical Specifications

• 250mA max current
• 190mA min guaranteed current
• Permanently short-circuit proof - without software shutdown
• Supports IEC62386 – 101 to 103, 201 to 209, 216 to 224, 250 to 253, 301 to 306, 332 to 333
