Meanwell HVGC Series | Constant Currents for 65W - 1000W
The constant current drivers are independent and designed for currents from 350mA up to 1000W power.
The products of the Meanwell HVGC series have a high quality manufactured metal housing with a wide range input.
The necessary protection is sufficiently provided. Thereby the HVGC series from Meanwell has an overload protection by current limitation and auto recovery. They are also protected against short circuit, overload, overvoltage and overtemperature.
Also included is a built-in PFC circuit. These aspects make the Mean Well HVGC series ideally suited for LED lighting applications.
High quality! In addition, Meanwell grants a 5-year manufacturer's warranty on the HVGC series.
Below you will find a list of all safety and EMC standards.
Curious? Then now…
- ·Application/IP-Code: IP20 - IP44 (Indoor), IP65/67 (Outdoor)
- ·Dimmable/Control: 1..10V, PWM
- ·Constant Current: 0,35A, 0,7A
delivery time 4-6 Weeks*
- ·Application/IP-Code: IP20 - IP44 (Indoor), IP65/67 (Outdoor)
- ·Dimmable/Control: 1..10V, DALI, PWM
- ·Constant Current: 1,4A, 2,1A, 2,8A
delivery time 4-6 Weeks*
- ·Application/IP-Code: IP20 - IP44 (Indoor), IP65/67 (Outdoor)
- ·Dimmable/Control: 1..10V, DALI, DALI2, PWM
- ·Constant Current: 2,8A, 4,2A, 5,6A, 11,2A
delivery time 4-6 Weeks*
- ·Application/IP-Code: IP20 - IP44 (Indoor), IP65/67 (Outdoor)
- ·Dimmable/Control: 1..10V, DALI, DALI2, PWM
- ·Constant Current: 2,8A, 4,2A, 5,6A
delivery time 4-6 Weeks*
- ·Application/IP-Code: IP20 - IP44 (Indoor), IP65/67 (Outdoor)
- ·Dimmable/Control: 1..10V, PWM
- ·Constant Current: 0,35A, 0,5A, 0,7A, 1,05A
delivery time 4-6 Weeks*
- ·Application/IP-Code: IP20 - IP44 (Indoor), IP65/67 (Outdoor)
- ·Dimmable/Control: 1..10V, PWM
- ·Constant Current: 0,35A, 0,5A, 0,7A, 1,05A, 1,4A
delivery time 4-6 Weeks*
Other features of the Mean Well HVGC types:
Types of dimming
(not the same for all versions):
- PWM
- 0-10V
- DALI
- Smart Timer
The Smart Timer Dimming Software is used for programming LED driver from MW equipped with the Smart Dim feature. The
connection between personal computer PC and driver is established via the “programmer” hardware interface from Mean well.
What function is provided?
Adjustable maximum output (AOC): This function adjusts the output current to a desired optimum value.
Constant light output (CLO): This function is utilized to compensate the depreciation of the luminous flux of a LED module over life time.
Customized dimming profiles: This function is perfect if there is no way to dim the driver by dedicated control lines due to a lack of infrastructure.
It allows automatic dimming via an integrated microcontroller.
Override: This function is to force the output to its maximum brightness.
Fade time: The adjustable time during each transition between dimming levels.
Lifetime: This function gives information of LED module operating hours and possible to indicate a signal at the end of the guaranteed lifespan of the LED module.
Dimming Profile DEMO: This function gives the demonstration of customized dimming profile for verification.
IP protection classes:
The IP (International Protection) protection classes indicate the insight through which a device is heard. These, the electronic devices, are the most important ones that are able, how they are, how they are, how they are, how they are, how they are, how they are.
- IP65
- IP67
Safety standards:
The European safety standards (EN) are the basis for safe products in all areas. These are required to be able to manufacture products that have basic safety requirements.
- EN61347-1
- EN61347-2-13
EMV-standards:
EMC stands for Electromagnetic Compatibility and describes the ability of a technical device not to disturb other technical devices unintentionally by electrical or electromagnetic effects - or to be disturbed by other devices. Meanwhile, Meanwell's HVGC products are well equipped.
- EN55015
- EN61000-3-2 Class C
- EN61000-3-3
- EN61547
Overview of individual models:
| Modell-Typ (Version) | Power | Currents | Tense |
| HVGC-65-350 (A/B) | 65.1W | 350mA | 18-186V |
| HVGC-65-500 (A/B) | 65W | 500mA | 13-130V |
| HVGC-65-700 (A/B) | 65.1W | 700mA | 9-93V |
| HVGC-65-1050 (A/B) | 65.1W | 1050mA | 6-62V |
| - | - | - | - |
| HVGC-100-350 (A/B) | 99.75W | 350mA | 29-285V |
| HVGC-100-700 (A/B) | 99.4W | 700mA | 15-142V |
| - | - | - | - |
| HVGC-150-350 (A/B) | 149.8W | 350mA | 42-428V |
| HVGC-150-500 (A/B) | 150W | 500mA | 30-300V |
| HVGC-150-700 (A/B) | 150.5W | 700mA | 21-215V |
| HVGC-150-1050 (A/B) | 150.15W | 1050mA | 15-143V |
| HVGC-150-1400 (A/B) | 149.8 W | 1400mA | 12-107V |
| - | - | - | - |
| HVGC-480-L (AB/ADA) | 480W | 1400mA | 137-343V |
| HVGC-480-M (AB/ADA) | 480W | 2100mA | 92-228.5V |
| HVGC-480-H (AB/ADA) | 480W | 2800mA | 68-171.7V |
| - | - | - | - |
| HVGC-650-L (AB/DA) | 649.6W | 2800mA | 92.8-232V |
| HVGC-650-M (AB/DA) | 651W | 4200mA | 62-155V |
| HVGC-650-H (AB/DA) | 649.6W | 5600-7000mA | 46.4-116V |
| HVGC-650-U (AB/DA) | 649.6W | 11200-14000mA | 24-58V |
| - | - | - | - |
| HVGC-1000-L (AB/DA) | 1003.2W | 2800mA | 150-380V |
| HVGC-1000-M (AB/DA) | 1008W | 4200mA | 95-240V |
| HVGC-1000-H (AB/DA) | 1008W | 5600mA | 70-180V |
