Product information "LED recessed office downlight 170 mm UGR "
LED recessed office downlight 18W, glare-free BILTON LEDON
This high-quality and innovative LED recessed downlight from the manufacturer BILTON LEDON with aluminium reflector and white frame has an excellent glare value of UGR<19 and is therefore ideal for lighting rooms where a glare-free environment is important. These include office and conference rooms, sales rooms, corridors, foyers and living Areas.
Features:
- Excellent glare value (UGR<19)
- Color temperature 4000 Kelvin
- High-gloss aluminum reflector
- Beam angle 60 °
- Installation diameter 140-150 mm, height 112 mm
- COB light source
- Up to 50,000 hours of operation
- Five-year manufacturer’s warranty
- Three-year full warranty on LED lights
Technical data of the LED downlight:
| Colour temperature | 4000K (Neutral White) |
| Luminous Flux | 1800 lm |
| Colour Rendering Index Ra | >90 |
| System efficacy | 100 lm/W |
| System performance | 18W |
| UGR | < 19 UGR |
| Beam Angle | 60° |
| Protection type | IP44 on room side, IP20 on ceiling side |
| Housing material | Aluminium / PC |
| Finish | Round, white (RAL9016) |
| External dimensions | 170 x 112 |
| Mounting dimensions | Ø 140-140 mm |
| Weight | 0,6 kg |
Note on the predecessor: This downlight is the successor to the LEDON NEWTON Office recessed downlight UGR <19 Article number.
Further technical data for this LED recessed downlight can be found in the datasheet in the Download tab.
| ·Color Temperature/Color: | 4000K |
|---|---|
| ·Dimmable/Control: | DALI, Push-Button |
| ·Hole diameter: | 150mm, 160mm, 165mm |
| ·Lamp shape: | Recessed ceiling |
BILTON LEDON Technology (BLTechnology)
is the high expertise specialist in the LED lighting sector.
From single LED modules to prefabricated x line configurations and LED luminaires Extensive range, the LED technology leader from Austria covers all this with its assortment. Due to the wide product range, the company offers the right product for every customer requirement. BLT. therefore sees itself as a project and system partner in architecture, trade and industry. With a clear focus on high-quality products and innovative, individual solutions, the focus is always on the CUSTOMER.
For more than 10 years we have been offering more than 100 products from the manufacturer BILTON LEDON worldwide.
Below is our portfolio of products. Tip: Use the filter function to quickly find the items you need, or give us a call.
BILTON LEDON Technology GmbH.
Gewerbepark Harham 2 - 5760 Saalfelden - Austria
Login
- Hole diameter - We recommend selecting the spots first, then drilling the holes. Otherwise the limitation is predetermined Output
- Light output in lumens, or wattage. How much light is needed in the room. There is no general answer to this question. Use the following link for the project enquiry
- Installation depth - usually a mandatory requirement in terms of drill hole depth or distance from suspended ceiling.
- Color temperature dimmability - We recommend modern options such as DALI or Casambi.
- Beam angle - For uniform room illumination. Usually determined by the distribution of the spots in the room and the room height.
- Fastening - Installation in false ceiling or concrete ceiling Glare - Depending on the viewing angle, lower LEDs in the spotlight can often no longer be perceived as a bright point of light, thus ensuring pleasant lighting.
If you have a lighting project and would like to use downlights, please use the link provided for our project enquiry form. We will try to answer all your questions.
