Product information "DALI light sensor LS module"
DALI-2 LS Light Sensor Module – Precise and Efficient Light Control
Control efficiently, illuminate intelligently – with the DALI-2 LS!
The DALI-2 LS Light Sensor Module from Lunatone is an intelligent addition to DALI and DALI-2 lighting control systems. It precisely measures light intensity and enables both constant light control and threshold-based lighting control. Flexible configuration and easy integration make this module an ideal choice for energy-efficient and comfortable lighting solutions in offices, schools, and public buildings.
Application and Example Use of the DALI-2 LS Module
The DALI-2 LS Module measures illuminance in a range from 0 to 2047 lux and responds to changes in ambient lighting. A typical application: In an office building, the module ensures that work surfaces remain consistently optimally lit, regardless of the daylight situation. This reduces energy consumption while enhancing visual comfort.
Advantages of the DALI-2 LS Light Sensor Module
- Simple installation via DALI bus, no separate power supply required
- Flexible operating modes: constant light control or light threshold control
- Optimization of energy consumption and increased comfort
- Compatible with DALI and DALI-2 systems
- Convenient configuration via DALI Cockpit software
- Expandable with multiple sensors within one DALI line
Technical Details of the DALI-2 LS Light Sensor Module
| Article Number | 68791433 | 68791433-AP | 68791433-ZD | 68791433-W16 | 68791433-W16-AP | 68791433-W16-ZD |
| Description | DALI-2 LS - Flush-mounted | DALI-2 LS - Surface-mounted | DALI-2 LS - Suspended Ceiling Installation | DALI-2 LS - Flush-mounted Traffic White | DALI-2 LS - Surface-mounted Traffic White | DALI-2 LS - Suspended Ceiling Traffic White |
| Mounting Type | Flush-mounted | Surface-mounted | Suspended ceiling | Flush-mounted | Surface-mounted | Suspended ceiling |
| Color | RAL9010 | RAL9010 | RAL9010 | RAL9016 | RAL9016 | RAL9016 |
| Measurement Range | 0-2047 Lux | |||||
| Power Supply | via DALI bus | |||||
| Protection Class | IP20 | |||||
| Operating Temperature | -20°C to +60°C | |||||
Safety and Installation Instructions
The module is connected directly to the DALI bus; no additional power supply is required. During installation, please observe the following:
- Installation only when voltage-free and by qualified personnel
- Wiring in dry and clean environments only
- Observe national regulations for low voltage installations
- No special cables required; standard installation material is sufficient
- The DALI signal is not SELV; low voltage installation regulations must be observed
For further technical details, information, and detailed installation instructions, please refer to the datasheet available in the download tab.
| ·Application/IP-Code: | IP20 - IP44 (Indoor) |
|---|---|
| ·Dimmable/Control: | DALI, DALI2 |
