Product information "DALI Converter with Switching Relays 1-10V"
DT8 DALI Converter/Interface Module with 1-10V Control for Tuneable White Applications
This DALI converter can be used to control 2 LED supplies with 1-10 V control inputs, such as the Meanwell HLG series. Thereby the interface module has a DALI DT8 address, which can be assigned to certain groups and scenes. Furthermore, this DALI converter implements an output mode for 2 separate channels, where the output current is 1 mA per channel. Here the output signals are automatically calibrated. In addition, switching relays for switching the ECG power supply on and off are integrated into the module. They also protect the DALI converter from high inrush current peaks of up to 160 A.
This item is available as a DIN rail module (-HS) or for remote / ceiling mounting (-DE).
Product Overview / Features:
- DT8 DALI converter for driving two 1-10 V control inputs, e.g. Meanwell HLG
- Galvanic isolation between DALI input and 1-10 V control voltage
- DALI DT8 address with Colour Type Tc (assignment of groups and scenes)
- Defined status in the event of a bus failure
- Supply directly via DALI line (no additional supply necessary)
- Output:
- Automatic calibration for output signals
- Output mode for 2 separate channels (CW, WW) with 1 mA output current each
- Integrated switching relays:
- For switching the ECG power supply on / off
- For high inrush current peaks up to 160 A
- Control of the relay contact linked to the dimming value
Characteristics / Specifications:
| Type | DALI RM16 2x0-10V DE | DALI RM16 2x0-10V HS |
| Article number | 89453857-DE | 89453857-HS |
| Device type | signal converter | |
| Configurable via DALI Cockpit | Yes | |
| Electrical data | ||
| Supply | From DALI bus | |
| type. Current consumption DALI | approx. 7 mA | |
| inputs | DALI | |
| Outputs (1-10V) | Channel 1: 1-10 V analog, current sink 1 mA Channel 2: 1-10 V analog, current sink 1 mA | |
| Relay contact switching voltage | 250 Vac / 400 Vac | |
| Maximum rated load relay | 1000 VA | 2000 VA |
| Maximum switching current relay | 8 A | 16 A |
| Maximum inrush current peaks relay | 160 A | 160 A |
| Contact type relay | 1 on / off | 1 changer |
| Switching cycles at 16A / 250Vac, resistive | 3x10^4 | |
| Max. Switching frequency relay | 0.1 Hz (full load) | |
| Technical data | ||
| Storage and transport temperature | - 20 ° C ... + 75 ° C | |
| Operating temperature | - 20 ° C ... + 65 ° C | |
| Protection class | IP20 | |
| Connection wires cross-section | 0.5-1.5 mm² | 0.5-2.5 mm² |
| Housing | Ceiling throw | DIN rail |
| Housing color | Gray | |
| Dimensions (LxWxH) | 120 x 30 x 22 mm | 98 x 17.5 x 56mm |
For more information on the DALI converter with switching relay 1-10V, please refer to the data sheet in the download tab.
| ·Application/IP-Code: | IP20 - IP44 (Indoor) |
|---|---|
| ·Color Temperature/Color: | Tuneable White |
| ·Dimmable/Control: | 1..10V, DALI DT8 |
| ·Lamp shape: | DIN Rail, Throw-in ceiling |
