Product information "3 CH DALI constant current (CC) dimmer"
Multi channel DALI constant current (CC) dimmer by Lunatone
- Every channel of the DALI constant current dimmer has its own DALI address
- Configuration and control via DALI
- For the direct control of LED modules with current input
- The outputs are dimmable from 1% to 100%
- Different variants for 350mA per channel in a small housing, further 1000mA per channel in a big housing are available
- Configuration via DALI cockpit and DALI USB interface
- Integrated short protection
The following versions are available:
Two channel versions, with 2 DALI addresses each (one address per channel)
With a collectice positive pole: 89453845-350DE
With a collectice minus pole: 89453845-350GMDE
Up to max. 2x 500mA output currents: 89453845-500
With a collectice positive pole: 89453845-500DE
With a collectice minus pole: 89453845-500GMDE
Up to max. 2x 700mA output currents:
With a collectice positive pole: 89453845-700
With a collectice minus pole: 89453845-700GM
Up to max. 2x 1000mA output currents:
With a collectice positive pole: 89453845-1000
With a collectice minus pole: 89453845-1000GM
Three channel versions, with 3 DALI addresses each (one address per channel)
With a collective positive pole: 89453846-350
With a collective minus pole: 89453846-350GM
Up to max. 3x 500mA output current
With a collective positive pole: 89453846-500
With a collective minus pole: 89453846-500GM
With a collective minus pole: 89453846-700GM
Four channel versions, with 4 DALI addresses each (one address per channel)
With a collective positive pole: 89453855-350
With a collective minus pole: 89453855-350GM
Up to max. 4x 500mA output current
With a collective positive pole: 89453855-500
With a collective minus pole: 89453855-500GM
Up to max. 4x 700mA output current
With a collective minus pole: 89453855-700GM
Other technical data:
- Output voltage range: 3V-45V (with 48V supply)
- Supply: 12VDC-48VDC resp. 56VDC
- Control input: DALI
- Temperature: -15 °C - 50 °C resp. -20 °C - 60 °C
- Protection type: IP20
- Condition after return: depends on the DALI settings
- Max. cross wire section: up to 2,5 mm²
- Dimensions: Check the data sheet
| ·Application/IP-Code: | IP20 - IP44 (Indoor) |
|---|---|
| ·Constant Current: | 0,35A, 0,5A, 0,7A, 1,0A |
| ·Dimmable/Control: | DALI, Push-Button |
